Part Number: SURTA3000XL

Output Power Capacity 2100 Watts / 3000 VA

Max Configurable Power  2100 Watts / 3000 VA

Nominal Output Voltage  208V

Output Voltage Note Configurable for 208 or 240 nominal output voltage

Efficiency at Full Load 91%

Output Voltage Distortion Less than 3%

Output Frequency (sync to mains) 50/60 Hz +/- 3 Hz user adjustable +/- 0.1

Crest Factor 3 : 1

Waveform Type Sine wave

Output Connections

Bypass : Internal Bypass (Automatic and Manual)

Input

Nominal Input Voltage 208V

Input Frequency 50/60 Hz +/- 5 Hz (auto sensing)

Input Connections

Cord Length 10 feet (3.05 meters)

Input voltage range for main operations 160 - 280V

Input voltage adjustable range for mains operation 100 - 280V

Other Input Voltages 240

Batteries & Runtime

Batteries & Runtime: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Included Battery Modules 2

Typical recharge time 2.50 hour(s)

Replacement Battery RBC44

RBC™ Quantity 1

Communications & Management

Interface Port(s) DB-25 RS-232,Smart-Slot

Available SmartSlot™ Interface Quantity 1

Control panel : LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : Overload and Bypass Indicators

Audible Alarm : Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Emergency Power Off (EPO) : Yes

Surge Protection and Filtering

Surge energy rating 480 Joules

Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

Maximum Height 17.00 inches (432 mm)

Maximum Width 5.10 inches (130 mm)

Maximum Depth 26.00 inches (660 mm)

Rack Height 3U

Net Weight 120.00 lbs. (54.55 kg)

Shipping Weight 140.00 lbs. (63.64 kg)

Shipping Height 13.68 inches (347 mm)

Shipping Width 23.73 inches (603 mm)

Shipping Depth 38.60 inches (980 mm)

Color Black

Environmental

Operating Environment 32 - 104 °F (0 - 40 °C)

Operating Relative Humidity 0 - 95%

Operating Elevation 0-10000 feet (0-3000 meters)

Storage Temperature 5 - 113 °F (-15 - 45 °C)

Storage Relative Humidity 0 - 95%

Storage Elevation 0-50000 feet (0-15000 meters)

Audible noise at 1 meter from surface of unit 55.00 dBA

Online Thermal Dissipation : 655.00 BTU/hr

Conformance

Regulatory Approvals : CSA,FCC Part 15 Class A,UL 1778

**The time to recharge to 90% of full battery capacity following a discharge to shutdown using a load rated for 1/2 the full load rating of the UPS.
